The Chip has a built- in automatic gain control(AGC), which automatically adjusts the amplitude of the input waveform to extent the dynamic range of the system.

　　IC packages: SOP8(150mil)

　　Simultaneously decodes two magnetic stripe tracks

　　AGC(Automatic Gain Control) for reading cards from 30% to 200% of International Standards Organization(ISO)7811 amplitude standard

　　Reads data from card swiping speeds from 3 to 75 IPS

　　Supports 75& 210 BPI(bit per inch) recording density

　　Supports power supply voltage range from 2.7V to 5.5V

　　Operation temperature range from-40℃ to +85℃

　　Low power sleep mode current 100uA with 3.3V supply

　　Low power operation during read decoding 3mA with 3.3V supply

　　Supports noise immunity
